The new Discover Series D3 underwater LED light from OceanLED, is ideal for boats that want to discover the many benefits of underwater lighting.

Overview
Superior Protection, Total Peace of Mind.

Superior Protection, Total Peace of Mind.

The Discover D3 is rated at IP69k, the highest achievable rating of protection against water ingress. IP69k goes one step further than the industry standard IP68, giving you additional protection and peace of mind. The rear of the light is protected from in-hull temporary submersion for boats where rough seas and waves sometimes flood the stern.

Compact Design

The D3’s compact dimensions make it ideal for tight fitting areas or smaller boats

Compact Design
Advanced Signature Optics - Wide Surface Beam

Advanced Signature Optics - Wide Surface Beam

The Discover D3 benefits from OceanLED’s signature optics (90° x 20°), producing an unrivaled optimal lighting effect.

Advanced Signature Optics - Narrow side Beam

The OceanLED signature optics produce a narrow side beam, that has minimal light loss, focusing the beam where you need it and penetrating further through the water.

Advanced Signature Optics - Narrow side Beam
Control your lights

Control your lights

Control your Discover D3 lights via the 3rd party switch or push button of your choice.

Consult the installation manual for more information

compact

Compact form factor for tight space installations

IP69k_logo2

IP69k Protection

peaceofmind

Rear Submersion Protection

Discover D3

Features

  • 700 Fixture lumens 700 Fixture lumens
  • Elliptical Beam Shape Elliptical Beam Shape
  • 90° Top Beam 90° Top Beam
  • 20° Side Beam 20° Side Beam
  • IP69k Protection
  • Rear Submersion Protection
  • Compact size for tight spaces and smaller boats
  • Can be used above water

Colours Available

  • Midnight Blue
  • Ultra White

SKU / Description

SKU Description
D3009W Discover D3 Flush Mount Ultra White
D3009B Discover D3 Flush Mount Midnight Blue

Technical

Fixture Lumens (Ultra White) 700
Beam Angle Rectangular 90° x 20°
Min-Max Operating voltage DC 10-30V DC
Current / Amp draw (12V DC) 0.7A@12V DC
Current / Amp draw (24V DC) 0.3A@24V DC
Correlated Colour Temp (White) 6500k
IP Rating (Front Face) IP69k
Rear Temporary Submersion Protection Yes
LED Manufacturer CR
Driver type Internal
Active Thermal Control (ATC) Yes

Mounting Recommendations

Boat size Up to 10m (33’)
Transom / Hull spacing 0.5 - 1.2m (2-4’)
Installation depth below waterline 150-200mm (6-8”)
Maximum Recommended Hull Thickness 50mm (2”)

Physical

Total weight 150g (0.33lbs)
Total Diameter (Including Bezel) 70mm (2.76”)
Diameter Of Body 40mm (1.57”)
Profile Of Fixture 70mm (2.76”)
Cable length 2m (79”)
Hole Cut-Out 44mm (1.73”)
Material (Bezel) UV protected, anti corrosive polymer
Material (Light Body) Hard Anodised Aluminium
Optics (90° / 20°) Hybrid Collimated
CE Approved Yes

Accessories

4 Way V DC Power Junction Box 019901
D3 & X-Series Isolating Mounting Kit 019913
