X-Series X4








SKU | Description |
---|---|
012301W | X4 Ultra White |
012302B | X4 Midnight Blue |
012312C | X4 Colours |
Product Description
Technical Details & Documents
-
Fixture Lumens Up to 1150 Minimum-Maximum operating voltage DC 9-32V DC Current / Amp draw (DC) 12V DC 0.8A 24V DC 0.4A IP Rating IP69k Certified -
Total weight 350g (0.78lbs) Extension cable length (standard) 9.84’ (3m) Hole cut-out for cable entry 0.5” (12.5mm) Material Grilamid -
Boat size up to 30’ (9m) Transom / Hull spacing 2-3’ (0.5-1m) Transom quantity 2-4 Installation depth (to top of fixture) 4-8” (10-20cm) -
OceanBridge Multizone Lighting Controller 013201 X-Series X4 Stainless Steel Bezel 011416 X-Series X4 Black Plastic Bezel PLS-000108 4 Way Power Junction Box (DC) 019901 OceanConnect 013204 D3 & X-Series Isolating Mounting Kit 019913

Supercharged Performance
Our signature underwater optics mean the X4 delivers lighting effects well beyond it’s 1,150 fixture lumens headline figure. By focusing and concentrating the light beam, our underwater optics allow the X4 to dominate lights with twice it’s power.

Suitable For All Boat Types
This easy to install surface mount light is suitable for use on almost any boat. Requiring just a 12.5mm hole cutout, coupled with its minimal footprint, the X4 is suitable for even the smallest of boats. Thanks to its intelligent thermal control and robust construction, the light can also be used above water, in high traffic areas.

Unrivalled Quality & Longevity
The X-Series X4 offers unrivalled reliability and longevity. The Grilamid construction makes the X4 UV and sea water resistant, meaning no degradation over time. The ultra-durable design uses a moulded single-piece Grilamid face, making water ingress almost impossible from the front of the light. Designed and manufactured exclusively in the United Kingdom, we never compromise on build quality.

Suitable For Use Above Water
The X4 is an exceptionally versatile light. Suitable for use almost anywhere, including above water areas, such as T-Tops where a flood light is needed. The intelligent thermal control of the X4 means it will never overheat, even in extreme temperatures. For high traffic, above water scenarios, where you need a robust and long-lasting lighting solution, look no further.
Gallery
