Explore E6 XFM

The Explore E6 XFM takes underwater lighting to breathtaking new heights. Born of the same technology used in our superyacht range, the E6 dominates its class. Available in full colour, dual and single colour options, producing up to 11,000 fixture lumens, the Explore E6 XFM creates unrivalled lighting effects.

With replaceable light cartridges, easy upgrade options, IP69K water ingress protection certification and our most advanced underwater light optics, the Explore E6 XFM is the powerhouse that does it all.

Learn more

Go to store Find a dealer

Colours available:

Product features:

Up To 11,000 Fixture Lumes

Advanced Underwater Optics

Ultra Reliable

IP69K Certification

Dual Mechanical Seal

C2P25158 - OceanLED - Icons30 - Tritonium Coating

Tritonium Coated Lens

C2P25158 - OceanLED - Icons28 - Cartridge Replacement

Light Cartridge Replacement

Easy Installation

RINA Certified

ABS Certified

Product variants:

SKU	Description
E6009W	Explore E6 XFM Ultra White
E6009B	Explore E6 XFM Midnight Blue
E6009BW	Explore E6 XFM Dual Blue/White
E6009CD	Explore E6 XFM Full Colour DMX

UNRIVALLED PERFORMANCE

Product Highlights

The flush mount design offers an ultra-low profile outer face, and allows the light cartridge to be removed from the rear, removing the need to haul the boat out for light maintenance or upgrades.

The E6 boasts the highest possible credentials for durability and water ingress protection with its IP69k certification. It benefits from our most advanced underwater optics, creating the coveted OceanLED light blade effect, cutting through water in a way no other brand can match. For those looking for the ultimate underwater light for larger vessels, look no further.

Up to 11,000 Fixture Lumens

For unmatched lighting effects.

Advanced Underwater Optics

Supercharging light performance.

Easy Light Cartridge Replacement

Save time and money.

Dual Mechanical Seals

For industry leading durability.

Fixture Lumens	Up to 11,000
IP Rating	IP69k Certified
Min-Max Operating voltage DC	10-32V DC
Dual Colour Current / Amp draw (12V DC / 24V DC)	7.8A / 4.7A
Colours DMX Current / Amp draw (12V DC / 24V DC)	6.8A / 3.2A
Min-Max Operating voltage AC	100V - 240V AC
Dual Colour Current / Amp draw (110V AC / 230V AC)	1,190mA / 570mA
Colours DMX Current / Amp draw (110V AC / 230V AC)	830mA / 400mA

Total weight	1.25kg (2.76lbs)
Total Diameter (Including Flange)	105mm (4.13”)
Diameter Of Body	80mm (3.15”)
Length	97mm (3.8”)
Clearance Required Behind the Light	100mm (3.93”)
Hole Cut-Out	83mm (3.25”)
Material	AB2 Aluminium Bronze

Boat size 12m +

Transom / Hull spacing 1 - 2m (3.2-6.5’)

Installation depth below waterline 25 - 30cm (10-12”)

Explore DC Power Kit	019903
Explore AC Power Kit	019904
DMX Touch Controller Kit (Colours DMX)	013001
DMX Touch Controller Kit (Dual Colour)	013003
E6/E7 DMX Terminator	011044
Control Cable and Terminator Kit	012923
Explore E6 Control Link Cable (3m)	012924
Explore E6 Control Link Cable (5m)	012925
Explore E6 Control Link Cable (10m)	012926
Explore E6 Control Link Cable (15m)	012927
Explore E6 Control Link Cable (20m)	012928
Mounting Tube Extension Kit	019905
Extension Tube Removal Kit	019907
Explore XFM Rear Enclosure Kit	019911

Unrivaled Lighting Effects

The Explore E6 XFM creates unrivalled lighting effects. Born of the same technology used in our superyacht range, the E6 dominates the high-power underwater light market. Using the industries most advanced underwater optics, the E6 creates the coveted OceanLED light blade effect, cutting through water like a knife. For those looking for the ultimate underwater light for larger vessels, look no further.

Superior Protection, Total Peace of Mind

The Explore E6 underwater light has been rigorously tested to IP69K, the highest protection standard available. The forged marine-grade aluminum bronze housing and specialist toughed colourless glass create a fortress of strength. The addition of advanced seals makes the E6 virtually bullet-proof, ensuring extended lifespans.

Easy Light Maintenance & Replacement

The XFM flush mount design of the E6 allows light cartridges to be serviced and replaced with ease, when the boat is still in the water. The light cartridge simply slides out the back of the mounting tube, and slotted back in. Servicing and replacing your underwater lights has never been easier.

Approved & Certified by Industry Bodies

The Explore E6 underwater light has been tested and approved by RINA and ABS. These type approvals mean the Explore E6 meets the industry bodies requirements for safety and durability, allowing them to be used on yacht builds without the need for a sperate design assessment.
